요새 오디오 회사치고, 포노앰프 안 내놓으면 이상하죠. 그래서 당연히 PS Audio에서도 출시했습니다.
0.15mV의 낮은 출력으로 MC카트리지를 사용할 수 있으며, 리모트를 통해 두가지 톤암을 선택 사용할 수 있습니다. RCA 혹은 밸런스 출력은 기본.
전원장치에서 출발하여 인지도가 높아지니 하이파이 회사로 변모해가는 PS Audio를 보니 격세지감이 느껴집니다.
| STELLAR PHONO PREAMPLIFIER | |
|---|---|
| Unit Weight | 21.6lbs. (9.8 kg) |
| Unit Dimensions | 17”W x 13”D x 3.25”H (43cm x 33.02cm x 8.255cm) |
| Shipping Weight | 25.1lbs (11.4 kg) |
| Shipping Dimensions | 22”W x 8”H x 17”D (55.88cm x 43.18cm x 20.32cm) |
| Color Options | Black Silver |
| Voltage Options (Factory set only) | Japan 100V North America 120V Europe/Asia/Australia/New Zealand 230V |
| Mains Power Input | IEC C14 |
| Idle Power Consumption | 26W |
| Fuses | 100V: T250V-2.0AH (2A Slow Blow) 120V: T250V-1.6AH (1.6A Slow Blow) 230V: T250V-1AH (1A Slow Blow) |
| Accessories Included | US (NEMA 5-15P) (100V/120V versions) Schuko (CEE7/7) (230V version) UK (BS1363) (230V version) Remote Control |
| Audio Inputs | RCA (Unbalanced) MM,MC |
| Audio Outputs | RCA (Unbalanced) 1 Stereo Pair XLR (Balanced) 1 Stereo Pair |
| DC Trigger | 3.5mm 12VDC (2) |
| Performance | All measurements are with both channels operating, gain set to low, and balanced outputs. Input frequency is 1kHz. |
| Gain | MM: 44dB, 50dB, 56dB MC: 60dB, 66dB, 72dB |
| Input Loading | MM: 47KΩ (100pF) MC: 60Ω, 100Ω, 200Ω, 47KΩ, Custom 1-1KΩ |
| Output Impedance | Unbalanced <200Ω Balanced <200Ω per leg |
| Frequency Response | 20Hz - 20KHz +/- 0.25dB |
| THD | 0.5V out @ 1kHz: <0.01% |
| Maximum Output | @1%THD: 24VRMS |
| Overload Margin | @1kHz: >22dB |
| S/N Ratio | MM: >82dB A-Weighted MC: >74dB A-Weighted |
| Interchannel Crosstalk | >74dB |
| Power Consumption | 26W |
