Model No

TAD-CR1MK2

Model

3-way bass reflex compact speaker

Drive Units

Bass: 20cm (8.0 in.) driver

Midrange/Tweeter: concentric 16cm (6.5 in.) cone/3.5cm (1.4 in.) dome

Performance Data

Frequency response: 32Hz to 100kHz

Crossover frequencies: 250Hz and 2kHz

Appropriate amplifier power: 50W to 200W

Sensitivity: 86dB (2.83V @ 1m free space)

Nominal impedance: 4Ω

Weight: 46kg (101 lbs.)

Dimensions: 341mm (13.4 in.) (W) × 628mm (24.8 in.) (H) × 444mm (17.5 in.) (D)
