Avantgarde Acoustic Uno SD Specifications
Frequency range satellite
290-22,000 Hz
Frequency range subwoofer
18-350 Hz
Power handling
50 Watt
Sensitivity (1 Watt/1 m)
> 107 dB
Crossover frequencies
290/2,800 Hz
Nominal impedance
18 Ohm
Recommended amplifier power
> 10 Watt
Recommended room size
> 16 sqm
Coplanar driver alignment
yes
OmegaDrive
yes
AirGate
yes
NatureCap incl. PolarizationPlus circuitry
yes
Horn type
spherical horn
Horn aperture angle
180 degrees
Horn diameter midrange
500 mm
Horn diameter tweeter
160 mm
Diameter midrange
127 mm / 5 inches
Diameter tweeter
25 mm / 1 inch
Driver size
250 mm / 10 inches
Number of drivers
1x XB10
Voice coil diameter
153 mm
Flux density
1.15 Tesla / 480 mm
Pole plate
low carbon steel
Membrane material
Paper/carbon fiber compound
Output power (RMS)
1x 500 Watt
Digital crossover
DSP
Equalizer
8 Band EQ
Digital room adjustment
yes
Inputs
1 x SPKR + 1 x XLR
iTRON voltage/current converter technology
patented
Fully balanced circuit
yes
Single-ended circuit
yes
Zero feedback
yes
Without negative feedback
yes
Power
2 x 100 Watt
High Performance Multi Contact Connector
yes
Semi-active version
yes
Fully active version with iTRON amplifier
yes
Dimensions width
500 mm
Dimensions depth
615 mm
Dimensions height (+/- 10 mm)
1,355 mm
Weight
81.5 kg
)
!
