| Specifications |
| General |
| Weight |
15.5 kg |
| Dimensions |
45 x 44.5 14.5 cm |
| Dimensions With packaging |
59 x 54 x 35.5 cm |
| Line Voltage |
230 / 50Hz |
| Power Consumption |
in Stand by < 0.5 VA
in idle < 20 VA
Maximum 21 VA
|
| Digital Inputs |
| Toslink |
| Conncetion |
Snap in Type |
| Wavelength |
650 nm |
| Nominal Input Power |
10 mW |
| Working input power range |
3 mW - 30 mW |
| Electrically / Galvanically Isolated |
Optically isolated |
| SPDIF |
| Conncetion |
RCA |
| Input Impedance |
75 Ohm |
| Nominal Input Power |
0.5 Vpp |
| Working input Voltage range |
0.2 - 5 Vpp |
| Electrically / Galvanically Isolated |
Galvanically isolated |
| USB Input |
| Connection |
USB Type B |
| Sampling Frenquency |
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz |
| Mode |
MCMI (Master Clock Mode Interdace), Asynchronous USB |
| Electrically / Gavanically isolated |
Galvanically isolated |
| Operating System Drivers |
Natively Suported, Without any special driver |
| Digital Ouput |
| Conncetion |
RCA |
| Input Impedance |
75 Ohm |
| Nominal Output Power |
0.5 Vpp |
| Electrically / Galvanically Isolated |
Galvanically isolated |
| Analog Outputs |
| Maximum Output Level |
Unbalanced RCA Out : 2 V @ 0 dBFS
Balanced XLR Out : 4 V @ 0 dBFS
|
| Output Impedance (RCA / XLR) |
100 Ohm / 200 Ohm
|
| Absolute Phase (RCA / XLR) |
in-phase / Pin-2 = In-Phase
|
| Total Harmonic Distortion (THD) |
< 0.001% @ 0 dBFS
|
| Signal to Noise Ratio (RCA / XLR) |
> 110dB (A-Weighted) @ 0 dBFS
|
| Channel Separation |
> 100dB @ 1kHz
|
| CD Section |
| CD Mechanism |
Slot drive, Frint loader
|
| Media |
Standard Compact Disc (RED BOOK), 12cm and 8cm discs
|
| Formats |
CD, CDR, CD-RW (Multi-Read)
|
| Book-Type |
CD-DA, CD-Extra, Extended CD, CD-Enhanced
|
| Laser Type |
780 nm (Reads Black CDR)
|
| Resolution / Sample Rate |
16 Bit / 44.1kHz (CD-Digital-Audio)
|
| Control Features |
Play, Pause, Stop, Skip FW, Skip BW, Repeat One, Repeat All, Shuffle
|
| CD-Text |
Album Title, Album Artist, Track Title, Track Artist
|
|
DAC Section
|
| Resolution |
24 Bit
|
| Sampling Frequencies |
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
|
| D/A Converter Type |
Multi-Bit Delta Sigma
|
| Jitter Reduction |
Digital/Analog Dual Nested PLL for effective jitter reduction
|
| Digital Oversampling Filter |
Psychoacoustic optimized filter of 4/5 Minimum Phase and 1/5 Linear Phase
|
| Analog Output Filter |
Group Delay Optimized Bessel Filter @ 40 kHz
|
)
!
