| Compatible Formats |
DSD (DSF, DFF), WAV, FLAC, AIFF, ALAC, M4A, APE and others |
| Bit and Sample Rates |
PCM up to 768kHz/32bit. DSD up to 256 DoP. Native DSD up to 512(Internal play only) |
| HDD for Music Library Storage |
Tray for User Installation 2 x SSD or 2.5 inch HDD |
| SSD for System and Cache |
480GB M.2 NVMe |
| DAC Chipset |
AKM AK4497 Dual-Mono Design with Dual-Mono Linear Power Supplies |
| Power Supply |
Full-Linear |
| Display |
8.8″ 1920 x 480 WIDE IPS COLOR LCD |
| Digital Audio Inputs |
1 x RCA SPDIF / 1 x BNC SPDIF / 2 x TOSLINK up to 24-bit / 192 kHz / DOP up to DSD64 |
| Data USB |
2 x USB 3.0 (Rear) |
| Dedicated Audio USB Port |
1 x USB AUDIO Class 2.0 |
| Ethernet |
1 x Double-Isolated Gigabit Ethernet |
| Volume Control |
-90 dB – 0dB, 0.5 dB step, Velocity Sensitive Operation Variable output control from front panel rotary knob, Conductor App and supplied IR remote control when used as preamplifier |
| Clock Structure |
Revised Full Differential System |
| Headphone Output |
6.5mm Unbalanced |
| Main Clock Accuracy |
OCXO Based Precision Jitter Reducing Clock Generator |
| CPU |
Intel N4200 Quad Core |
| Internal UPS |
Super Capacitor Based UPS (uninterrupted power supply) |
| USB Audio Output |
PCM: Up to 32bit / 768kHz – DSD: DoP Up to 128- Native DSD Up to 256 |
| Analog Audio Outputs |
Unbalanced (RCA): 2.0 or 2.7 Vrms / Balanced (XLR): 4.0 or 5.4 Vrms selectable |
| User Software |
Aurender Conductor iPad App, iPhone App (Lite Version), Android App (Lite Version), Tablet App |
| Dimensions |
Unit with foot : 430 x 111 x 355 mm / 16.9 x 4.4 x 14.0 inch
Unit only : 430 x 98 x 355 mm / 16.9 x 3.9 x 14.0 inch
|
| Weight |
37.5 lbs / 17.0 kg |
)
!
