Analog audio inputs
Connectors : RCA x 3 pairs (RCA 2 can be used as an AV pre-input)/ XLR x 2pairs
Input impedance : LINE :10kΩ
Input sensitvity : At rated output : 510 mV / At 800 mV output : 200 mV
Maximum input level : 12 V
Analog audio output
Connectors RCA x 2 pairs / XLR x 2 pairs
Output impedance : RCA 47Ω / XLR 100 Ω
Total harmonic distortion : 0.0006% (RCA) / 0.0004% ( XLR)
Frepuency response : 1Hz - 200 kHz (-3 dB ) / 3Hz - 50 kHz (-0.2 dB)
Signal-to-noise ratio (S/N) : 116 dB (2 V input, A-weight )
Gain : +12 dB
Rated outpu : 2 V
Maximum output level : 7.5 V (RCA output, 1kHz, 0.003%) /15V (XLR output, 1kHz, 0.003%)
General
Power supply :AC 230V 50Hz / AC 120V 60Hz / AC 220V 60Hz
Power consumption : 21 W
Extemal dimensios (W x H x D) (including protrusions) :445 x 162 x 457 mm (17 5/8"x 6 1/2"x 18")
Weight : 32 kg (70 5/8 lb)
Included accessories : Power cord x 1 / Remote control (RC -1156) x 1 / Batteries for remote control (AA) x
1 Felts x 4 / Owner’s manual x 1 / Warranty card x 1
)
!
