ABSOLARE SINGLE-ENDED TRIODE SIGNATURE BALANCED

Design: All Tube, Single-Ended Architecture (Transformer coupling in XLR models)

Attenuator: 48 steps with discrete resistors, remote controlled

Tubes: 2x 12AU7 / ECC82 or E80CC - Every unit comes with select NOS tubes

Bandwidth: 20Hz -20KHz within +/-0.2dB

Input: 3 in RCA Model / 4 in XLR Model / 2 RCA + 2 XLR in RCA/XLR Model

Input impedance: 100 Kohm for RCA Model, 10Kohm for XLR Model

Maximum Gain: 18 dB

Outputs: 2 in RCA Model / 2 in XLR Model / 1 RCA + 1 XLR in RCA/XLR Model

Output impedance: 750 ohms

Dimensions: 38.2 x 54.5 x 14.6 cm (WxDxH), excl. feet

Weight: 18.9 Kg
