Fully discrete, DC-coupled Class A circuit topology
Microprocessor-controlled, 43-step, fully balanced relay volume attenuator for best sonic performance based on a minimalist contingent of ultra-precision resistors
New, high-speed, discrete single-ended Class A input buffer for best possible sonic performance
Optional PCM/DSD DAC module with one USB, 2 x SPDIF, 1 AES and 1 optical input. PCM up to Fs = 384kHZ, DSD up to DSD512
Optional MM/MC phonostage module
Local shunt regulators for optimal noise suppression
Input level matching to prevent abrupt level changes
Ultra-short signal path
Minimal internal wiring
Gold-plated Swiss Neutrik XLR sockets for 2 balanced inputs and 1 output
Gold-plated phono sockets with Teflon insulation for 3 inputs and 2 outputs
Fixed-level AV throughput, balanced or unbalanced, for uncompromising integration with surround preamplifier.
Large Vacuum Fluorescent Display for easy legibility
Adjustable display lighting
Backlit touch-sensitive front panel controls
12V DC link input and output
Green Bias control – compatible with any Gryphon power amplifier
)
!
